DIPLOMA IN ELECTRONICS AND TELECOMMUNICATION ENGINEERING

Computer Lab - I/II

Equipment List: Computer Systems 48

Analog Electronics Lab

Equipment List: 20 MHZ Oscilloscope AM / FM (2 MHZ) Function Generator || Analog & Digital Trainer || Flip Flop Trainer || PLL Frequency Multiplier & Synthesizer || Implementation of IC-723 basic HIGH/LOW REG || Precision Halfwave & Full wave rectifier !! Linear IC trainer Kit. || Electrical Theorem Kit with Four Theorems || Thevenins Theorem(MNO KNB 18).

Electronic Devices & Circuit Design

Equipment List: 100 MHZ Oscilloscope with 1GS/S ||Bread Baord Trainer System || Digital Tariner Kit || Discrete Component Trainer Board || IC 810 As Audio Amplifier Trainer || 20 Mhz Oscilloscope || AM/FM Function Generator || CRO 25 MHZ DUAL TRACE with component tester || Generator sine square/1 MHZ || 1 MHZ function generator || Semiconductor diode with 4 meter || Digital multimeter || Power supply 30 V/1amp || Soldering iron with Bench Setup || Digital multimeter model: DMM4011 || Digital lab/ST 2611.

Embedded System Lab

Equipment List: Arm-7 Development Board with all interbase on Board with Power supply || Arm-7 Development Board with all interbase on Board(SPJ- SYSTEM) with Power supply || SBC-51: 8051 based Microcontroller Trainer || SMPS power supply || DYNA 51 microcontroller trainer with LCD display || A to D converter(ADC 01 : 8 bit) || Stepper Motor || Cable & connector set with keyboard || Testronics power supply with 92 B || Testronics power supply with 92 C.

Robotics Lab & Industrial Cell

Equipment List: FireBird V 2560 || Spark V Robot || FireBird V P89V51RD2 adapter card || FireBird V LPC2148 adapter card || Zigbee Modules 100m range || Zigbee Modules adapter || Metal-gear Servo Motors || Servo Motor Based Gripper kit for the Fire Bird V robot || Sharp GP2Y0A21YK0F infrared range sensor ( 10cm to 80cm ) || Electric Hand Drill Machine + Drill Bit Set || Hand Grinder || Micro Soldering Station, Bench Vice, PCB Soldering Clamp, Assorted pliers, Hammer.

Digital Electronics Lab

Equipment List: Digital Multimeter || Thermister (NTC ) Char.(MODEL-SA-108) || Analog Multimeter Demonstrator (SE801) || Transducer Trainer (RTD, Thermister, Thermocouple) || Logic Gate Trainer || Half Adder & Full Adder || Multiplexer (16:1) || Demultiplexer (1:16) || Flip Flop Trainer || Asynchronous Up / Down Counter || 20 MHz Oscilloscope || AM / FM (2 MHz) Function Generator || Analog & Digital Trainer || BCD To Excess -3 Converter || Study Of Logic Gate With IC Number || Combined Unit On Adder And Subtractor.
